| SKU No. |
DP00070 |
DP00071 |
DP00070KVB |
|
| Fuel type |
Pellet (Premium grade or better) |
Pellet (Premium grade or better) |
Pellet (Premium grade or better) |
Pellet (Premium grade or better)
|
| Recommended heating area-ft² |
500 - 2,000 |
500 - 2,000 |
500 - 2,000 |
500 - 2,000 |
| Hopper capacity |
60 lb (27 kg) |
80 lb (36 kg) |
60 lb (27 kg) |
|
| Maximum burn time |
51 h |
69 h |
51 h |
51 h |
| Maximum heat input rate |
39,260 BTU/h (11.5 kW) |
39,260 BTU/h (11.5 kW) |
39,260 BTU/h (11.5 kW) |
|
| Overall heat output rate |
6,648 BTU/h (1.95 kW) to 28,540 BTU/h (8.36 kW) |
6,648 BTU/h (1.95kW) to 28,540 BTU/h (8.36kW) |
6,648 BTU/h (1.95 kW) to 28,540 BTU/h (8.36 kW) |
6,648 BTU/h (1.95 kW) to 28,540 BTU/h (8.36 kW)
|
| Average overall efficiency |
70.3 % (HHV) - 75.8 % (LHV) |
70.3 % (HHV) - 75.8 % (LHV) |
70.3 % (HHV) - 75.8 % (LHV) |
70.3 % (HHV) - 75.8 % (LHV)
|
| Optimum efficiency |
0.784 |
0.784 |
0.784 |
78.40% |
| Optimum heat transfer efficiency |
73 % |
73 % |
73 % |
73 % |
| Burn rate |
1.2 - 4.7 lb/h |
1.2 - 4.7 lb/h |
1.2 - 4.7 lb/h |
|
| Average particulate emissions rate |
0.96 g/h |
0.96 g/h |
0.96 g/h |
0.96 g/h |
| Average CO (12) |
7.6 g/h |
7.6 g/h |
7.6 g/h |
7.6 g/h |
| Average electrical power consumption-ignition cycle |
3.02A (360W) |
3.02A (360W) |
3.02A (360W) |
|
| Average electrical power consumption for continuous operation |
1.3 - 2.5A (51 - 140W) |
1.3 - 2.5A (51 - 140W) |
1.3 - 2.5A (51 - 140W) |
|
| Combustion technology |
Top-feed |
Top-feed |
Top-feed |
Top-feed |
| High-efficiency certified appliance |
Yes, EPA 2020 approved |
Yes, EPA 2020 approved |
Yes, EPA 2020 approved |
|
| Electronic igniter |
Yes |
Yes |
Yes |
Yes |
| Flue outlet diameter |
3" |
3'' |
3" |
3'' |
| Type of chimney |
ULC/ORD-C441, CAN/ULC S609, UL 641 (TYPE L) |
ULC/ORD-C441, CAN/ULC S609, UL 641 (TYPE L) |
ULC/ORD-C441, CAN/ULC S609, UL 641 (TYPE L) |
ULC/ORD-C441, CAN/ULC S609, UL 641 (TYPE L)
|
| Baffle type |
Stainless steel |
Stainless steel |
Stainless steel |
|
| Approved for an alcove installation |
Yes |
Yes |
Yes |
Yes |
| Approved for a mobile home installation |
Yes, with fresh air intake |
Yes, with fresh air intake |
Yes, with fresh air intake |
Yes, with fresh air intake
|
| Shipping Weight |
277 lb (126kg) |
286 lb (130 kg) |
319 lb (145 kg) |
|
| Door type |
Single, glass with cast iron frame |
Single, glass with cast iron frame |
Single, glass with cast iron frame |
Single, glass with cast iron frame
|
| Glass type |
Ceramic glass |
Ceramic glass |
Ceramic glass |
|
| Glass surface – dimensions (Width X Height) |
15 3/4" X 8 1/8" |
15 3/4'' X 8 1/8'' |
15 3/4" X 8 1/8" |
|
| Glass air-wash system |
Yes |
Yes |
Yes |
Yes |
| Premium quality blower included (CFM) |
176 |
176 |
176 |
176 |
| Noise level at 6 feet |
47 dBa (+/- 3 dBa) - 60 dBa (+/- 3 dBa) |
47 dBa (+/- 3 dBa) - 60 dBa (+/- 3 dBa) |
47 dBa (+/- 3 dBa) - 60 dBa (+/- 3 dBa) |
47 dBa (+/- 3 dBa) - 60 dBa (+/- 3 dBa)
|
| Overall dimension (Height) |
32 5/8'' |
36 1/8'' |
32 5/8'' |
32 5/8'' |
| Overall dimension (Width) |
25 1/8'' |
25 1/8'' |
25 1/8'' |
25 1/8'' |
| Overall dimension (Depth) |
29 1/2'' |
29 1/2'' |
29 1/2'' |
29 1/2'' |
| Voltage and frequency |
120 VAC / 60 Hz |
120VAC / 60Hz |
120 VAC / 60 Hz |
|
| USA standard (emissions) |
ASTM E2779 |
ASTM E2779 |
ASTM E2779 |
|
| Canadian Standard (emissions) |
CSA B415.1-10 |
CSA B415.1-10 |
CSA B415.1-10 |
|
| USA standard (safety) |
UL 1482, ASTM E1509 |
UL 1482, ASTM E1509 |
UL 1482, ASTM E1509 |
|
| Canadian standard (safety) |
ULC S627 |
ULC S627 |
ULC S627 |
ULC S627 |
| Tested and listed as per applicable standards |
By an accredited laboratory (CAN/USA) |
By an accredited laboratory (CAN/USA) |
By an accredited laboratory (CAN/USA) |
By an accredited laboratory (CAN/USA)
|
| Warranty |
Limited lifetime |
Limited lifetime |
Limited lifetime |
|
